The prominent features of the large inclination belt conveyor in material transportation
Large inclination belt conveyor is also known as the gear band conveyor, which can be widely used in coal, grain, building materials, chemical industry, water and metallurgy and other departments, and in terms of conveying height, conveying volume, structure installation, supporting area, etc. Other transportation equipment is more advantageous than. Here we compare it with the conveying equipment such as the promotioner and the scraper conveyor, so that users can understand and choose.
Large inclining belt conveyor band is composed of baseband, gear and partitions. The appearance of the baseband is the same as ordinary conveyor belt, but the horizontal stiffness is larger: the gear is wavy, and the partition can be divided into T -shaped according to its different sections. Type C and TC type. Type T is suitable for occasions of inclination β≤40 °. Type C is suitable for occasions with inclination β> 40 ° and better material liquidity. TC type is suitable for occasions with large material viscosity.
Compared with other conveying equipment, the advantages of large inclination belt conveyors:
(1) Transportation height: Through years of unremitting efforts, the large -scale belt machine produced by conveyor manufacturers continues to increase the height (up to 203m), which is wider than the applicable range of the promotioner and other conveying equipment.
(2) Transfer volume: The transportation capacity has reached 6000T/h, which has greater conversion compared to ordinary improvement conveyors. The large number of ordinary boosters reaches 800m3/h.
(3) Installation is more convenient: Before the conveyor is upgraded, the conveyor needs to be embedded as a support for a fixed tail frame, and the large inclination belt conveyor only needs to be installed at the venue. Labor intensity.
(4) The structure is simpler and easier for maintenance. The structure of the large inclination belt conveyor is simple, not a sealing design. Therefore, during maintenance of the maintenance personnel, it can be carried out without a complex process. The improved machine is to close the header, tail wheel, chain, fighting and other components inside the case, so it is more troublesome during maintenance. Compared with other transportation equipment such as scraper conveyors, it is also much simpler.
(5) It is easier to match other equipment. Due to the large -scale belt conveyor, it is divided into three parts of the design: the bottom horizontal section, tilt section, and head horizontal section. Therefore, the bottom or head horizontal section can be extended according to the user requirements, and the transportation of ordinary horizontal fixed belt conveyors is completed, and a multi -purpose function is achieved, so it is easier to use other equipment.
(6) The large inclination belt conveyor can design the tilt angle according to the need, the inclination angle is within the range of 0-90 °, and the large conveyor and other conveyors such as the scraper conveyor can only reach 45 degrees, which cannot meet the needs of users in many aspects.
(7) Reliable running, without the card chain, floating chain, broken chain phenomenon, and bucket improved phenomenon that often appear in the baked conveyor. Its reliability is almost equal to the usual belt conveyor;
(8) The equipment occupies a smaller area, saving a lot of space. The layout of the large inclination belt conveyor can save more space for users, and the tilt section will not affect other equipment in the lower part.
Large inclination belt conveyors have more advantages in material conveying volume, layout form, and transportation efficiency than other conveying equipment. At the same time, it is much lower than other conveying equipment in terms of maintenance and failure. Production costs, improve transportation efficiency.
